MODIFICATION & COMPATIBILITY

RASCAL Pods - Photo Courtesy of USAF - Christian Turner

THINK DTS

  • Ultra-small, networked data acquisition
  • Streaming and onboard recording
  • Outstanding worldwide technical support 24/7/365

RECOMMENDED DTS PRODUCTS

MODIFICATION TESTING

RAPID DEPLOYMENT DATA ACQUISITION UNITS (DAU)

The Challenge:

  • Installation of flight test instrumentation (FTI) may require days to months for a single test
  • Time required to disassemble complex sensor cabling network to central FTI
  • Limited options to handle test modifications (ie. additional channels or points of interest)
  • Space, weight and power constraints, especially on aircraft store and unmanned aerial systems/vehicles (UAS/UAV)
  • Limited access to aircraft and instrumentation, schedule changes and delays
  • Instrumentation cannot easily be moved or altered to support last minute changes
  • Access limitations based on wired solutions, especially for new areas of interest
  • Data fidelity, reliability and power issues due to long, complex cable runs

The Solution:

  • SLICE6 AIR miniature data acquisition units
  • Standalone, networked or integrate into existing Ethernet-based FTI systems
  • Standardized network support (IRIG CH10 or TmNS)
  • IEEE 1588 PTPv2 timing supported via Ethernet
  • Ultra‐small, embeds on or in test article near sensors, eliminating long cable runs
  • Easy and quick installation supports test modifications and prewired test articles
  • Universal analog sensor conditioning (Bridge, IEPE, TC, Voltage) – all in one package
  • IP67 rated for extreme environments including high shock, vibration, temperature
  • 500 g shock hardened for destructive tests and installations aboard expandable stores
  • Data streaming and onboard recording to 16 GB flash memory for data redundancy

For more information contact sales@dtsweb.com

“As air space is becoming the new highway in the sky, in-flight testing is critical for safety, reliability and comfort.”
